BMW E36 - Pin Assignments (X17)

BMW
BMW
BMW
6211.0Ćb
1998
Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
X17
Pin Type Description/Function Connection
1 E Trailer turn signal indicator control Hazard flasher relay
2 A Vehicle speed signal Various control modules
3 M Ground supply, terminal 31 for indicator and
warning lamps
Ground point
4 E Voltage supply, terminal 15 for instrument
cluster electronics
Front power distribution box, fuse 23
5 E Voltage supply, terminal 15 for battery
charge indicator
Ignition switch, terminal 15
6 E Ground supply, terminal 61 for battery
charge indicator
Generator
7 Not used
8 E Fog light indicator control Front power distribution box, fuse 15
9 A Sound tone signal Chime module
10 A Information signal, fuel tank content On-board computer
11 E Slip control system warning lamp (ABS)
control
Slip control module (ABS) (323i, 328i, M3)
12 E ASC signal ASC control module
13 A TI-measurement signal (fuel consumption) Engine control module (DME)
14 E Seat belt warning lamp control Driver’s seat belt switch
15 E S/A reset/service interval indicator reset Data link connector
16 E Voltage supply, terminal R Front power distribution box, fuse 46
17 A Coolant temperature sensor Coolant temperature sensor
18 E Coolant temperature sensor Coolant temperature sensor
19 E Oil pressure warning lamp control Oil pressure switch
20 Not used
21 E Ground Ground point (with ASC)
21 E Slip control system warning lamp (ABS)
control
Slip control module (ABS/ASC) (323i, 328i,
M3)
ABS control module (ABS)
22 E Ignition key warning/audible ignition key
warning
Ignition switch
23 E Driver’s door open Driver’s door jamb switch
