Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
24 A Dimmer signal/brightness information
signal for connected control modules
On-board computer or multi-function clock
25 Not used
26 E Central indicator lamp/check-control On-board computer or multi-function clock
X271
Pin Type Description/Function Connection
1 A Fuel level sensor Fuel tank sensors
2 Not used
3 A Ground supply for fuel tank sensors and
vehicle speed sensor
Fuel tank sensors and vehicle speed
sensor
4 E Position signal TW Vehicle speed sensor
5 Not used
6 Not used
7 Not used
8 Not used
9 Not used
10 Not used
11 Not used
12 Not used
