Install the housing cover
Note
This cover is not relevant for the safe operation of the Wallbox.
Attach the housing cover
1. Attach the housing cover at the top, and
ensure that the hooks on the housing cover are
correctly attached 1.
2. Press the cover downwards and then swing
the housing cover 2 backwards.
The housing cover must slide into the bottom
guides without any major resistance.
CAUTION
Make sure that the housing cover is
correctly positioned in the housing guide
on all sides. There must be only a uniform
minimum gap.
Locks
1. Press the bottom section of the housing cover
on to the Wallbox until the locks 1 fully engage.
48
