Technical data
Electrical data
Charging mode: Mode 3 as per IEC 61851-1
Cable feed: Surface-mounted or flush-mounted
Connection cross-section: Minimum cross-section (depending on the cable
and type of installation):
- 5 x 2.5 mm² (16 A nominal current)
- 5 x 6.0 mm² (32 A nominal current)
Supply terminals: Connection cable:
- rigid (min.-max.): 0.2 – 16 mm²
- flexible (min.-max.): 0.2 – 16 mm²
- AWG (min.-max.): 24 – 6
- flexible (min.-max.) with wire-end ferrule
with/without plastic sleeve:
0.25 – 10 / 0.25 – 10 mm²
Temperature rating of supply terminals: 105 °C
Rated current (configurable connection values): 10 A, 13 A, 16 A, 20 A, 25 A or 32 A
3-phase or 1-phase
Mains voltage: 220-240 V ~
220/380 - 240/415 V 3N~
Mains frequency: 50 Hz/60 Hz
Mains configuration: TT/TN/IT
Overvoltage category: III as per EN 60664
Rated short-time current resistance: < 10 kA effective value to EN 61439-1
Fuse (in the domestic installation): The fusing must comply with the local
regulations depending on the socket/cable
version (see rating plate).
DC residual current monitoring: ≤6 mADC (integral)
Ventilation during charging: Not supported
