BMW MINI Wallbox Plus - Electrical Specifications; Interface Specifications

Electrical data
Version with charging socket: Type 2 standard socket with shutter: 32 A/400
VAC to EN 62196-1 and EN 62196-2
Protection class: I
Device's IP protection class: IP54
Protection against mechanical impact: IK08
Interfaces
Enable input [X1]: Enable input for external authorisation:
Connection cable:
- Cross-section (min.-max.): 0.08 – 4 mm²
- AWG (min.-max.): 28 – 12
RS485 connection [X2]: Extra-low safety voltage <50 V
Connection cable:
- Cross-section (min.-max.): 0.08 – 4 mm²
- AWG (min.-max.): 28 – 12
Diagnostic connection [X3]: RJ45
Ethernet1 connection [X4]: LSA+ terminals
USB connection [X5]: USB jack type A (max. 500 mA)
RFID (optional): MIFARE cards or tags to ISO 14443 or ISO
15693 Tag-It
or Tag-It cards or tags to ISO 15693
Mechanical data
Dimensions (W x H x D) 399 x 652 x 202 mm (without connector)
Weight: approx. 10 kg (depending on version)
Assembly (stationary): On the wall or on the column
