Push release lever 2 down,
continuing until it engages.
Turn key to LOCK position in
pannier lock and remove.
Remove case
Turn key to RELEASE position
in pannier lock.
Handle pops out.
Pull carry handle 3 up as far as
it will go.
Case is released and can be
removed.
Mount case
Fold up handle as far as possi-
ble.
Insert case in brackets 4.
Press handle 3 down until it
engages.
Turn key to LOCK position in
pannier lock and remove.
8
151
z
Accessories
