in the instrument cluster. This
situation can occur if the battery
was disconnected.
Tire inflation pressures
with Tire Pressure Control
(TPC/RDC)
OE
The tire pressures are
shown adjusted for tem-
perature on the multifunction
display and are always relative
to the following tire air temper-
ature:
68 °F (20 °C)
The figure on the left side 1 in-
dicates the front tire's inflation
pressure, while the figure on the
right 2 shows the inflation pres-
sure in the rear tire. Immediately
after switching on the ignition,
"-- --" is indicated.
RDC sensor is not active
min 19 mph (min 30 km/h)
(The RDC sensor does not
transmit a signal to the motor-
cycle until this minimum speed
has been exceeded.)
If the pressure in a tire drops to
a critical level the corresponding
status indicator shows red.
The tire warning symbol
also appears on the display.
The general warning lamp
flashes red.
Further information on
BMW Motorrad RDC can
be found starting from page
( 110).
3
42
z
Displays
