Rear brake-disk thickness min 0.18 in (min 4.5 mm), wear limit
Free travel of brake actuation (Rear wheel brake) Approx. 0.04 in (Approx. 1 mm), at piston
Wheels and tires
Recommended tire combinations You can obtain an overview of the current tire
approvals from your authorized BMW Motorrad
retailer or on the Internet at www.bmw-
motorrad.com.
Front wheel
Front wheel design Aluminum cast wheel
Front-wheel rim size 3.5"x17"
Front tire designation 120/70 - 17
Front wheel load at unladen weight 306 lbs (139 kg)
Permissible front wheel load max 390 lbs (max 177 kg)
Permissible front-wheel imbalance max 0.2 oz (max 5 g)
Rear wheel
Rear wheel design Aluminum cast wheel
Rear-wheel rim size 5.5"x17"
Rear tire designation 180/55 - 17
Rear wheel load at unladen weight 298 lbs (135 kg)
10
168
z
Technical data
