CB11

Stepper Motor

Illustrated Step by Step Instructions

Step 1 Preparing the Stepper Motors for Mounting

Step 1a Align one of the Set Screws of the GT2 Pulley

(H84) to the flat surface of the Stepper Motor

Shaft. Snug the Set Screw so that it engages

the shaft but still allows the Drive Pulley to

slide down the shaft.

Flat Surface of Shaft

Set Screw
