16
Quantum MAX X-Frame Assembly
Required Wood Components
Part #
Description
Qty
QX1
Rail Support
18
QX2
Torsion Arm
6
EQX2
Extension Torsion
Arm
2
QX3
Inner Frame Mid
Support
4
QX4
Outer Frame Mid
Support
3
EQX4
Extension Frame Mid
Support
1
QX5
Frame Side Support
2
EQX5
Extension Frame Side
Support
2
