57
Required Hardware
Part
#
Description
Qty
H95
M6 x 35 Machine
Screws
4
H18
M6 Locknuts
4
H40
Eccentric Spacer
4
H41
Eccentric Washer
4
H42
Bearing Fender
Washer
4
H44
SG20U Bearing
4
ZD12
ACME Nut Assembly
1
H97
M5 X18 Machine
Screw
2
H49
M5 Lock Nut
2
H14
M4 x 16 Machine
Screw
20
H15
M4 Nut
20
H48
M5 x 30 Machine
Screw
1
H93
M5 Square Nut
1
