69
Y Carriage Assembly and Z Assembly
Required Wood Components
Part #
Description
Qty
QY1
Z Stepper
Motor Mount
1
QY2
Carriage Top
Support
1
QY3
Bearing
Retainer
Plate
1
QY4
Carriage
Frame
1
QY5
Carriage Side
Support
2
QY6
Z Rail Stop
1
QY7
Carriage
Bottom
Support
1
