91
QG9
Gantry
Side
2
QG10
Gantry
Lower Side
Brace
2
Required Hardware
Part
#
Description
Qty
H95
M6 X 35 Machine
Screws
8
H18
M6 Lock Nut
8
H40
Eccentric Spacer
4
H41
Eccentric Washer
4
H42
Bearing Fender
Washer
12
H44
SG20U Bearing
8
H14
M4 x 16 Machine
Screws
120
H15
M4 Nut
120
