BobsCNC QUANTUM MAX User Manual

124
Illustrated Step by Step Instructions
Step 1 Attach four X Rail Stops (QR1) on the front and back
Frame End Supports and secure each with two M4 x
20 Machine Screws and Lock Nuts as shown.
Make sure the hole
located between the
Machine Screws in the
Rail Stop is clearly visible
through the rectangular
opening in the Frame
End Support
