BobsCNC QUANTUM MAX User Manual

18
Required Hardware
Part
#
Description
Qty
H14
M4 x 16 Machine
Screw
240
H15
M4 Nut
240
H47
M4 Lock Nuts
16
WARNING There are two long and two
short Torsion Arms in the Max Front X-Frame
Assembly. The long Torsion Arms are located
on the front of the Assembly. The short
Torsion Arms are located at the rear of the
Assembly.
Illustrated Step by Step Instructions
The Quantum Max X Frame consists of two components, the Front X
Frame Assembly and the Rear X Frame Assembly. The following steps
will cover building the Rear X Frame Assembly.
