Assembly Recommendations:
Use a large, flat, clean work surface for assembling your Quantum
Max.
All Screws (unless noted) should be installed snug, then rotated 1-2
½ turns.
Apply LOCTITE 242™ or clear fingernail polish to all M4 X 16 mm
Machine Screws that are used to secure plywood pieces. Machine
Screws that are secured with Lock Nuts do not need LOCTITE™.
Light sanding of the wood components may be performed if desired.
Painting or applying stain with a clear coat will provide extra
protection to the wood components.
Clean the rails with acetone to remove rust preventative and apply a
light coat of PTFE (Teflon®) lubricant.
We recommend using strips of 1-inch blue painter’s tape behind the
T-Slots to help hold the Nuts in place during assembly.
Lock Nuts are never used to secure components that have T-Slots.
They are only used to mount components where the Nut is not
held in a T-Slot.
CAUTION This kit contains numerous small
components that pose a choking risk for small
children and pets. Keep kit pieces in a secure
location out of the reach of small children and
pets.
