71
CB11
Stepper
Motor
1
H37
M3 x 10
Machine
Screw
4
H88
M3 washer
4
ZD5
Aluminum
Helical
Coupler
1
ZD3
626-2RS
Bearing
1
ZD4
6mm Split
Locking
Collar
1
ZD1
ACME
Screw
1
H66
Small
Shim
Washer
2
H15
M4 Nut
30
H14
M4 x 16
Machine
Screw
30
H54
Stress
Proof Steel
Z-Rail
2
