Toplift / Toplift ECO
20 92023200095
picture 5-7
picture 5-8
picture 5-9
5.7 Solar-Platform Standard
The solar-platform-standard may be used in
combination with standard or tilting carriage.
This platform is particularly designed for the
transport of smaller solar and photovoltaic instal-
lations.
The modules are fixed by means of a continu-
ously variable clamping device with rubber vibra-
tion pad.
max. capacity: 200 kg
5.8 Solar-Platform adjustable
The adjustable solar platform can be used with
standard or tilting carriage. It is mainly used for
the handling of larger solar elements. The base
frame is rubber cushioned. The lateral bars can
be extended to 1.55 m.
max. capacity: 200 kg
5.9 Sheet transport bed with adjust-
able inclination
The sheet transport bed with adjustable inclina-
tion serves to convey large sheets and panels
(gypsum board panels, windows, etc.). The parts
to be conveyed may have a maximum width of
150 cm, a maximum height of 210 cm and a
maximum depth of 15 cm. The platform bed can
be used with a carriage or a tilting carriage. With
the tilting carriage combination it must be en-
sured that the tilting function is not activated.
The use of the sheet transport bed with adjust-
able inclination is advantageous, as the con-
veyed material can be horizontally unloaded at
the loading point and then fits through window
openings due to the second tilting option.
The material is secured by chains.
max. capacity: 150 kg
