Toplift / Toplift ECO
25 92023200095
5.10.4 Handling of the furniture platform with pluggable side guards
• Regulate both telescopic supports in such a way, that furniture platform is in horizontal position. For
bulky goods and for loading of the platform, both side guards can be removed respectively placed
in horizontal position.
• Safety catch stop has to secure that side guards will not fall out when mounted in horizontal posi-
tion
A T T E N T I O N !
The centre of gravity of the cargo to be transported must always be placed in the centre and as
near as possible to the guide rails. If - in the case of bulky pieces of furniture - the feet extend
beyond the bottom of the platform, then it is allowed to load the side guards with no more than 30
kg each.
• Always secure load by means of belts against falling down.
For loading or unloading in upper position, the platform can be drawn towards the window sill or
over the balcony parapet.
• Unlock and hinge down the extension rail.
• Release the lock with the lever and simultaneously pull the furniture platform in forward direction.
• Allow locks to snap in again.
A T T E N T I O N !
During the „lifting“ and „lowering“ movements, the furniture platform must always be snapped in
transverse to the lift rails and be arrested within the carriage telescopic rail in the rear hole. Front
part of extension rail has to be tilted upwards.
• Securing rings have to be pulled out.
• During movement, the furniture platform can be pulled backward out of the extension rail. For this,
safety hook to be pushed upwards and locks to be released.
NOTE!
A detailed description / instruction for each furniture platform, explained at the pages
before, can be requested by the manufacturer.
