Toplift / Toplift ECO
21 92023200095
5.9.1 Handling of the Sheet transport bed with adjustable inclination
1
Upper frame
2 base frame
3 support 21 cm
4 support 45 cm
5 floor extension
6 lateral extension
picture 5-9.1
WARNING ! Danger due to the inclination function of the sheet transport bed!
If the supports (3; 4) are not secured by the bolted connection or if the snap pins are not engaged, the loaded
or unloaded platform bed will tilt. Danger of crushing!
Before loading or using the sheet transport bed, check the bolt lock and the snap pins and lock if
necessary.
WARNING ! Danger due to falling load!
Loads may fall due to incorrect operation or insufficient securing.
So not exceed the permissible payload (depending on the position of the supports, see 5.9.1 )
Never stand underneath the load or the load-bearing device.
Always secure the load with the chains supplied by the manufacturer.
Never extend the floor of the sheet transport bed when loaded.
