Böcker Toplift - 2 TECHNICAL DETAILS

Toplift / Toplift ECO
8 92023200095
2 TECHNICAL DETAILS
(CONSTRUCTION)
TOPLIFT
225 Universal
TOPLIFT
225 – 110 V
TOPLIFT
234
TOPLIFT
240
TOPLIFT
Eco
Hoisting speed:
25 (30) m/min 25 (30) m/min 34 m/min 20/40 m/min 25 m/min
Capacity: 250 kg 200 kg 250 kg 230 kg 150 kg
Standard height:
11,30 m 11,30 m 11,30 m 11,30 m 11,30 m
Max. eaves height: 20,50 m 20,50 m 20,50 m 20,50 m 20,50 m
Weight drive unit: 54 kg 54 kg 54 kg 54 kg 47 kg
Rope diameter: 6 mm 6 mm 6 mm 6 mm 5 mm
Standard rope length: 44 m 44 m 44 m 44 m 44 m
230 V / 50 Hz 110 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz 220 V / 50 HzMotor voltage:
110 V / 60 Hz 110 V / 50 Hz
Control voltage: 24 V 24 V 24 V 24 V 24 V
Motor power: 1,3 kW 1,3 kW 1,3 kW 0,6/1,2 kW 1,6 kW
Max. operating time
40 % ED 40 % ED 40 % ED 40 % ED 40 % ED
Supply line 3 x 2,5 mm²
3 x AWG10“
(3 x 5.26mm²)
3 x 2,5 mm² 3 x 2,5 mm² 3 x 2,5 mm
2
Length supply line max. 40 m max. 40 m max. 40 m max. 40 m max. 40 m
Fuse 16 A träge 32 A träge 16 A träge 16 A träge 16 A träge
sound pressure level
Lpa
<70dB <70dB <70dB <70dB <70dB
(FURNITURE)
TOPLIFT
Furniture
(MV)
TOPLIFT
Furniture
(M1)
TOPLIFT
Furniture
(M2)
Hoisting speed:
36 m/min 34 m/min 20/40 m/min
Capacity: 200 kg 200 kg 200 kg
Standard height:
11,30 m 11,30 m 11,30 m
Max. eaves height: 20,50 m 20,50 m 20,50 m
Weight drive unit: 57 kg 54 kg 54 kg
Rope diameter: 6 mm 6 mm 6 mm
Standard rope length: 44 m 44 m 44 m
Motor voltage: 220 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz
Control voltage: 24 V 24 V 24 V
Motor power: 2,2 kW 1,3 kW 0,6/1,2 kW
Max. operating time
40 % ED 40 % ED 40 % ED
Supply line 3 x 2,5 mm
2
3 x 2,5 mm² 3 x 2,5 mm²
Length supply line max. 40 m max. 40 m max. 40 m
Fuse 16 A time lag 16 A time lag 16 A time lag
sound pressure level
Lpa
<70dB <70dB <70dB
