C/ BT 2025 CLASSIC (ref. 915147) and BT2025 ALPHA (ref. 915149)

• Attach the panel on the 2 posts with the 4 clamps and the threaded rods (D).

• Connect the wires (see paragraph VI - B).

Note: for wall mounting use the pear-shaped holes on each panel (C).

R4,50

118

1130

1076

120 maxi

1500

1200

Pear-shaped hole for wall mounting

with screws and plugs Ø8

Clamp Threaded rod
