11
D/ BT 2045 SCORE (ref. 915150 and 915151)
• Attach the SCORE panel on the 2 posts with the 4
clamps and the threaded rods (B).
• Connect the wires (see paragraph VII - A).
Note: for wall mounting use the pear-shaped holes on each panel (A).
A
Pear-shaped hole for wall mounting
with screws and plugs Ø8
R4,50
73
121
A
2000
2400
567 25,5
32,5
560
122
160 maxi
SCORE panel
Flange
Threaded rod
Cable cover
B
B
