12
E/ BT 2045 CLASSIC (ref. 915152)
• Attach the panel on the 2 posts with the 4 clamps and the threaded rods (D).
• Connect the wires (see paragraph VII-B).
NB: when mounting to a wall, use the teardrop-style holes provided in each corner of the casing (B).
Flange
Threaded rod (A)
B
Pear shaped holes for wall mounting
with Ø8mm screws and wall anchors
R4,50
73
121
122
160 maxi
22,5
660,5
663,5
2000
