17
IV - Attaching the advertising panels
A/ Peripheral advertising panels for BT 2025 SCORE & CLUB (915 180) or BT 2045 SCORE & CLUB
(915 181)
• This advertising panel can be installed above or below the scoreboard.
• Position the advertising panel, above or below the scoreboard, on the 2 support posts with the clamps
and threaded rods (A).
For mounting under the scoreboard: the xing clamps are to be placed at the bottom.
For mounting above the scoreboard: the xing clamps are to be placed on top.
• Position the assembly at the desired height and tighten the clamps.
