Bodet Score BT2000 Series User Manual

21
A - A
H
B - B
F
C
Stainless steel flat washer Ø8
Stainless steel serrated washer Ø8
Stainless steel nut HU M8
Stainless steel
screw H M8x25
D
Stainless steel
screw H M8x16
Stainless steel serrated washer Ø8
Stainless steel nut HU M8
BT2045 green plate support
Stainless steel flat washer Ø8
Stainless steel flat washer Ø8
E
Stainless steel serrated washer Ø8
Stainless steel nut HU M8
BT 2045 panel flange
Stainless steel threaded rod M8-200
Stainless steel
screw H M8x16
Stainless steel
screw H M8x16
F
Stainless steel nut HU M8
Stainless steel
serrated washer Ø8
BT 2000 advertising plate reinforcement
Stainless steel screw HM8x25
G
Stainless steel nut HU M8
BT2045 green plate support
BT 2045 bottom advertising bracket
Stainless steel nut HU M8
Stainless steel screw
TCBL Cru Z M4x16
Stainless steel serrated washer Ø8
H
Stainless steel nut HU M8
Stainless steel serrated washer Ø8
BT2045 advertising
attachment bracket
