25
A-A ( 1 : 15 )
E
H
B-B ( 1 : 15 )
F
C ( 1 : 1 )
D ( 1 : 1 )
E ( 1 : 4 )
G-G ( 1 : 2 )
BT2045 advertising
attachment bracket
Stainless steel nut HU M4
H ( 1 : 2 )
F ( 1 : 1 )
Stainless steel flat washer Ø8
Stainless steel serrated washer Ø8
Stainless steel serrated washer Ø8
Stainless steel nut HU M8
Stainless steel nut HU M8
Stainless steel
screw H M8x25
Stainless steel
screw H M8x16
BT2045 green plate support
Stainless steel flat washer Ø8
Stainless steel serrated washer Ø8
Stainless steel nut HU M8
BT 2045 panel flange
Stainless steel threaded rod M8-200
Stainless steel
screw H M8x16
Stainless steel
screw H M8x16
Stainless steel
screw TH M8x25
Stainless steel
screw
TCBL Cru Z A2 M4x16
Stainless steel nut HU M8
Stainless steel nut HU M8
Stainless steel nut HU M8
Stainless steel nut HU M8
Stainless steel
serrated washer Ø8
Stainless steel
serrated washer Ø8
Stainless steel flat washer Ø8
Stainless steel flat washer Ø8
BT2045 green plate support
Stainless steel serrated washer Ø8
BT2000 advertising
attachment bracket
BT 2000 HZ advertising plate reinforcement
