Bodet Score BT2000 Series User Manual

30
DCF antenna wiring
Timer panel
Master panel
Timer panel wiring
HOME alpha score panel
To master panel mains
terminal strip
868 MHz modem
+V
GND
RT-
RT+
+V
GND
RT-
RT+
GPS MDM
T °C
ON
2187
ON
215 64
ON
21 3
RX
TX
GND
RS232
L
N
T
+
+
-
-
1 42 3
Power supply from HOME Alpha score panel Mains power supply Command from HOME Alpha score panel readout
To Alpha
module supply
+V
GND
RT-
RT+
MDM
T °C
Dips
GND / Green
RT- / Brown RT+ / White
Flat cable
Power supply
Yellow
Green
Brown
White
Brown
White
To Alpha module
Temperature sensor wiring
Temperature probe
A
B
D
E
C
Wiring of a GPS antenna is not appropriate for the BT 2045 Alpha.
