93
1. Gear position display
If all lights flash while shifting gear, it
indicates the shifting is not completed
yet. Simply wait until the shifting com-
pletes or retry the shift with the gear
shift button.
If all lights flash continuously, it indi-
cates a damaged sensor (gearbox). Al-
though the vehicle can still be operat-
ed in this condition, downshifting may
increase engine “braking”. Drive slow-
ly. See an authorized Bombardier ATV
dealer as soon as possible.
Other Indicator Lights
Located on right side of cluster. They
light up to monitor different functions.
Quest MAX Series
1. Engine temperature
2. Oil pressure
3. Neutral
4. Reverse
5. Park
Traxter MAX Series
1. Engine
2. High intensity
3. Auto (autoshift mode)
4. Reverse
5. Neutral
If REVERSE and NEUTRAL lights flash
continuously, it indicates a damaged
sensor (sub-transmission). Although the
vehicle can still be operated in this con-
dition, downshifting may increase en-
gine “braking”. Drive slowly. See an
authorized Bombardier ATV dealer as
soon as possible.
IF AUTO light flashes, it indicates a
possible problem with the TPS sensor.
The manual mode is immediately se-
lected. See an authorized Bombardier
ATV dealer as soon as possible.
Indicator Lights Description
Engine (RED)
Quest MAX Series
When this indicator light is ON, it in-
dicates the engine is overheating.
V01A5CY
1
V04I0GY
1
2
3
4
5
V01A5DY
1
2
3
4
5
