MAINTENANCE CHART
The maintenance is very important; if you are not familiar with safe service prac-
tices and adjustment procedures, see your authorized Bombardier ATV dealer.
I: Inspect, verify, clean, adjust, lubricate, replace if necessary
C:Clean
L: Lubricate
R: Replace
INITIAL 10 h
INSPECTION
OR 250 km (150 m.) ➀
EVERY
TO BE
PERFORMED BY
25 h
OR 625 km (388 m.)
50 h
OR 1250 km (777 m.)
100 h OR 1 YEAR
OR 2500 km (1553 m.)
200 h OR 2 YEARS
OR 5000 km (3107 m.)
ENGINE/TRANSMISSION
Engine/transmission oil and filter ➃ RR Customer
Engine/transmission oil strainer cleaning C Customer
Engine mount fasteners IIDealer
Exhaust system IIDealer
Spark arrester C Customer
Condition of seals IIDealer
Coolant ➃ I ➁ R Customer
Radiator cap/cooling system pressure test IIDealer
Radiator condition/cleanliness (air ducts and radiator fins) ➂ II Customer
Rewind starter rope condition I Dealer
Clutch and transmission operation I Dealer
Drive belt I Dealer
Cleaning/condition of drive and driven pulleys C Dealer
CVT air inlet/outlet duct condition/cleanliness and sealing II Dealer
FUEL SYSTEM
Air filter ➃ C ➂ R ➂ Customer
Fuel lines and connections IIDealer
Fuel tank strainer R Dealer
Carburetor adjustment IIDealer
ELECTRICAL SYSTEM
Spark plug(s) IRDealer
Battery electrolyte level/connections/vent condition II Customer
Wiring harnesses, cables and lines IIDealer
Condition of ignition switch and start/stop switch ➃ IICustomer
Condition of lighting system
(HI/LO intensity, brake light, headlamp aiming, etc.) ➃
IICustomer
Winch connections Refer to ATV Winch Operator’s Manual Customer
DRIVE TRAIN
Drive shaft boot and protector ➃ II Customer
Drive shaft joint I Dealer
Front/rear propeller shaft joint IL Dealer
Wheel bearings condition I Customer
Front differential and rear axle oil, seals and vent IIRDealer
