1192 Peak current 0.01 % I
FI,N
100 % I
FI,N
FI,N
: Nominal value of Frequency inverter
o: Overload capability of Frequency inverter
10.2.8 Change sense of rotation
The parameter Change sense of rotation 1199 reverses the rotating direction of the
motor.
0 -
Off
Motor rotates forward
(clockwise)
Motor rotates reverse
(anti clockwise)
1 -
On
Motor rotates reverse
(anti clockwise)
Motor rotates forward
(clockwise)
BONFIGLIOLI VECTRON defines with view on the motor A side and correct connection
of the motor phases the sense of rotation clockwise (forward) with a positive set value.
With a changed sense of rotation, the motor reverses with the same set value. Existing
gear boxes and transmissions have to be considered.
The sense of rotation can only be changed while the output stage is inhibited.
With the parameter Change sense of rotation 1199 the sense of direction of the com-
plete system (motor control and encoder evaluation) is reversed.
When the sense of direction is different between motor and encoder, this can be
changed by two actions:
1.) Change the track A and track B at the encoder inputs at the terminals of ACU.
2.)
Change the evaluation of the sense of rotation of the connected encoder with
parameter 490 respectively 493.
10.3 Internal values
The following parameters are used for internal calculation of motor data and do not
require any set-up.
No. Description No. Description
399 Internal value 01 706
402
707
508
708
702
709
703
745
704
798
06/13 Operating Instructions ACU 127
