15.3.8 Warning Mask
The Warning mask signals via a digital signal if an afore configured warning applies.
The configuration of the Warning mask is carried out via Create warning mask 536
.
Warnings and controller status messages can be combined. This enables internal or
external control using a common output signal. The display of Warning 269
and
Controller Status 275 is not affected by the Warning mask.
Select a setting 1 … 43 for message activation.
Select a setting 101 … 143 for deactivation of a message.
Create Warning Mask 536
Function
0 - No Change Configured warning mask is not modified.
1 - Activate everything
The warnings and controller status messages stated
are linked in the warning mask.
2 - Activate all Warnings
The warnings reports stated are linked in the warn-
ing mask.
3 -
Activate all Controller
States
The controller status reports stated are linked in the
warning mask.
10 -
Warning Ixt
The frequency inverter is overloaded.
11 - Warning Short-Term Ixt
Overload reserve for 1 s less the Warning limit
short-term Ixt 405 has been reached.
12 - Warning Long-Term Ixt
Overload reserve for 60 s less the Warning limit
long-term Ixt 406 has been reached.
13 -
Warning Heat Sink
Temperature
Max. heat sink temperature T
K
of 80 °C minus the
Warning Limit Heat Sink Temp. 407 has been
reached.
14 -
Warning Inside Tem-
perature
Max. inside temperature T
i
of 65 °C minus the
Warning Limit Inside Temp. 408 reached.
15 - Warning Limit
The controller stated in Controller status 355 limits
the reference value.
16 - Warning Init Frequency inverter is being initialized.
17 -
Warning Motor Tem-
perature
Warning behavior according to parameterized Oper-
ation mode Motor temperature 570 at max. motor
temperature T
PTC
.
18 -
Warning
Mains Failure
Phase monitoring 576 reports a phase failure.
19 -
Warning Motor Protec-
tive Switch
Operation Mode 571 for the motor protective
switch has triggered.
20 - Warning Fmax
The Maximum frequency 419 has been exceeded.
The frequency limitation is active.
21 -
Warning
Analog Input MFI1A
The input signal is lower than 1 V/2 mA according to
the operation mode
Error/Warning Behavior
453.
22 -
Warning
Analog Input EM-S1INA
The input signal on the analog input of an expansion
module is lower than 1V/2mA according to the oper-
ation mode Error/Warning Behavior 453.
23 -
Warning
System bus
A slave on the system bus reports a fault;
warning is only relevant with the EM-SYS option.
24 - Warning Udc
The DC link voltage has reached the type-dependent
minimum value.
25 -
Application Warning
A warning application is signaled.
30 -
Controller
Udc Dynamic Operation
Controller is active according to the Operation Mode
670 for the voltage controller.
31 - Controller Shutdown
The output frequency in the case of a power failure
is below the
Shutdown threshold
675.
32 - Controller Mains Failure
Failure of the mains voltage and power regulation
active according to Operation Mode 670 for the
voltage controller.
06/13 Operating Instructions ACU 187
