Borri E2001 COMPACT - Page 37

Front panel AC-UPS GD 128x64
OMX76014 Rev. A 19
4.4.1 Input Settings
The Input Settings menu allows changing the acceptability intervals for voltage and
frequency of the mains.
Drop-down menu
Data displayed
MAX VOLTAGE
(Maximum voltage)
Sets the percentage of the upper acceptability
threshold of the RMS input mains voltage.
MIN VOLTAGE
(Minimum voltage)
Sets the percentage of the lower acceptability
threshold of the RMS input mains voltage.
MAX FREQUENCY
(Maximum frequency)
Sets the percentage of the upper acceptability
threshold of the input mains frequency.
MIN FREQUENCY
(Minimum frequency)
Sets the percentage of the lower acceptability
threshold of the input mains frequency.
4.4.2 Inverter Settings
The Inverter Settings menu allows changing the acceptability intervals for voltage
and frequency of the inverter output.
Drop-down menu
Data displayed
MIN VDC INPUT
(Inverter input
minimum voltage)
Sets the minimum input voltage of the inverter,
under this threshold the inverter will switch off.
4.4.3 Output Settings
The Output Settings menu allows changing the acceptability intervals for voltage and
frequency of the output.
Drop-down menu
Data displayed
MAX VOLTAGE
(Maximum voltage)
Sets the percentage of the upper acceptability
threshold of the RMS output voltage.
MIN VOLTAGE
(Minimum voltage)
Sets the percentage of the lower acceptability
threshold of the RMS output voltage.
MAX FREQUENCY
(Maximum frequency)
Sets the percentage of the upper acceptability
threshold of the output frequency.
MIN FREQUENCY
(Minimum frequency)
Sets the percentage of the lower acceptability
threshold of the output frequency.
