Front panel AC-UPS GD 128x64
20 OMX76014 Rev. A
4.4.4 Battery settings
The Battery settings menu only available for configurations with the batteries
installed, allows setting the battery data.
Drop-down
menu
Section Description
SIZE
(Battery
dimension)
-
Sets the dimension of the battery (e.g.
following replacement of the battery after
rectifier start-up).
ALARMS LEVEL
(Setting the alarm
levels)
HIGH FLOATING
(Vmax buffer float charge
(A8))
High voltage of floating charge: sets the
threshold for alarm A8
LOW FLOATING
(Vmin buffer float charge
(A9))
Low voltage of floating charge: sets the
threshold for alarm A9
MIN. LEV. 1
(Battery level min 1)
First level: sets the threshold for the alarm
A16
MIN. LEV. 2
(Battery level min 2)
Second level: sets the threshold for the
alarm A17
MIN. LEV. 3
(Battery level min 3)
Third level: sets the threshold for the
alarm A18
AUTOM. TEST
(Automatic test
parameters
setting)
ENABLE/DISABLE
(Enables/disables the
automatic test)
- Enables automatic testing of the battery
if disabled.
- Disables automatic testing of the battery
if enabled.
INTERVAL DAYS
(Sets the interval of the
automatic test)
Sets the interval (days) between an
automatic test of the battery and the next.
START TIME
(Sets the start hour of the
automatic test)
Sets the time in which the rectifier
executes the automatic test of the battery
.
