4.4.5 Battery charger settings
The Battery charger settings menu only available for configurations with the batteries
installed, allows setting the float charge parameter for buffer, manual and rapid.
Drop-down
menu
Section Description
FLOATING
(Floating
charge
settings)
VOLTAGE
(Floating charge)
Sets the floating charge.
CURR. LIM. BATT.
(Automatic mode max. battery
current)
Sets the maximum recharge current.
COMP. TERM.
(Thermal compensation)
Sets the thermal compensation constant to
protect the battery from any excess
temperatures.
BOOST
(Boost charge
settings)
ENABLE/DISABLE
(Enables/disables)
Enables or disables both types of boost
charge (timed or automatic).
BOOST MODE
(Boost charge mode)
(1)
Sets the automatic boost charge mode
(current or voltage).
VOLTAGE
(Boost charge voltage)
Sets the voltage level for boost charge.
SAFETY TIMER
(Boost charge safety timer)
Sets the maximum time permitted for the
rectifier to remain in boost charge mode.
FORCED DURATION
(Timed boost charge)
Sets the duration of timed boost charge.
DURATION FORCED
(Standby time
Boost charge -> floating charge)
Sets the boost charge standby time for
floating charge.
CURRENT B -> F
(Boost charge current -> floating
charge)
Sets the boost charge current threshold at
the floating charge.
CURRENT F -> B
(Floating charge current -> Boost
charge)
Sets the floating charge current threshold at
the boost charge.
VOLTAGE B -> F
(Boost charge voltage -> floating
charge)
Sets the boost charge voltage threshold at
the floating charge.
VOLTAGE F -> B
(Floating charge -> Boost charge)
Sets the floating charge voltage threshold at
the boost charge.
MANUAL
(Manual
charge
settings)
ENABLE/DISABLE
(Enables/disables)
Enables/disables the manual charge.
STARTING VOLT
(Manual start-up voltage)
Sets the manual start-up current.
MAX CURRENT
(Manual start-up maximum battery
current)
Sets the manual start-up recharge current.
SAFETY TIMER
(Manual charge timer)
Sets the maximum time permitted for the
rectifier to remain in manual charge mode.
(1) Boost charge mode also defines the type of threshold (if amperometric or voltmetric) for the passage from floating
charge to boost charge.
