Bosch AVENAR detector 4000 - Table of Contents

AVENAR detector 4000 Table of contents | en 3
Bosch Sicherheitssysteme GmbH
User manual
2023-06 | 07 | F.01U.283.550
Table of contents
1
Product Description 5
2
System Overview 7
2.1 System Description 7
2.2 Functional Description of the Sensor Technology 7
2.2.1 Optical Sensor (Smoke Detector) 7
2.2.2 Thermal Sensor (Heat Detector) 8
2.2.3 Chemical Sensor (Gas Sensor) 8
2.3 Two-color LED 8
2.4 Features 8
2.5 Compatibility 9
2.6 Accessories 9
2.6.1 Detector bases 9
2.6.2 Detector Base Sounders 10
2.6.3 Acoustic/visual alarms 11
2.6.4 Remote Indicators 11
2.6.5 End-of-line modules 12
2.6.6 Mounting and protection accessories 13
3
Basic installation and configuration notes 15
4
Programming 16
4.1 FAP-425-DOTC-R and FAP-425-DOTCO-R 16
4.2 FAP‑425‑DOT‑R / FAP‑425‑OT‑R / FAP‑425‑OT 18
4.3 FAP‑425‑DO‑R / FAP‑425‑O‑R / FAP‑425‑O 19
4.4 FAH‑425‑T‑R 20
5
Connection 21
5.1 Installing the Base 21
5.2 Connection 21
5.2.1 Connecting the MS 400/MS 400 B 22
5.2.2 Connecting the FAA‑MSR 420 22
5.3 Installation of the detector head 23
5.4 Detector removal 24
5.5 Address setting 24
5.6 Installing Remote Indicators 25
6
Order Information 29
6.1 Detector Variants 29
6.2 Detector Bases 29
6.3 Detector Accessories 29
6.4 Installation Accessories 30
6.5 Detector Base Sounders 30
6.6 Remote Indicators 30
6.7 Service accessories 31
7
Maintenance and Service 32
7.1 Detector Type Encoding 33
7.2 Test instructions 33
7.2.1 Test instructions for detectors with optical sensor 33
7.2.2 Test instructions for chemical and thermal sensor 34
7.3 Diagnostic data 34
7.4 Warranty 36
7.5 Repair 36
