Bosch B4512 Owner's Manual

Callout
Number
Description
4 [ALL], [PART], and [BYPASS] keys
5 [MENU] key
6 [CMD] key (Command)
7 [ESC] key (Escape
8 [HELP] key
9 Programmable function keys
10 Status indicators (refer to Status indicators
overview, page 124)
Your security system provides quick access to functions through
the keypad menus.
To access menus using a B92x, press [MENU]. Press [PREV] or
[NEXT] to scroll through the list of functions programmed by your
security company. To initiate the function shown on the display,
press [ENTER] or press the corresponding number key, as
indicated in the on-display instructions (for example, Press 2 for
Status menu). To exit a specific menu and return to the previous
level, press [ESC]. To exit and return to idle text from any level of
the menu structure, press and hold [ESC].
Control Panels
B92x keypad operation overview | en 119
Bosch Security Systems, Inc. 2015.01 | 02 | F.01U.307.371

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
