16.2 Outputs
Your security company programs outputs for automatic control
and/or keypad control of devices such as premises lighting or
entry gates. An output is a device that is controlled by the
security system. Contact your security company for further
information regarding the use of outputs in your security system.
Use this function to select outputs to turn on or off. Outputs on
your security system can control other systems, lighting for
example.
Security systems using B5512/B4512/B3512 control panels are
not UL investigated for access control.
Turning outputs on and off:
1. Open the Main menu.
2. Press [Actions] to open the menu.
3. Press [Outputs] to open the menu.
4. Enter your passcode and press [ENTER].
5. Use
/[NEXT] to select the desired output value, or use the
number keys to enter the value.
6. Press [Turn On] or [Turn Off].
7. Escape from the menu.
Control Panels
B94x/B93x Actions menu | en 73
Bosch Security Systems, Inc. 2015.01 | 02 | F.01U.307.371

Bosch B4512 Specifications

General

Control Panel Type	Hybrid
Wired Zones	8
Outputs	2
Programmable Outputs	2
Onboard Ethernet	Yes
Cellular Communication	Optional
Series	B Series
Partitions	2
Type	Control Panel
Model	B4512
Manufacturer	Bosch
Input Voltage	16.5 VAC
Communication Formats	Contact ID, SIA
Power Supply	16.5 VAC
Backup Battery	12 V, 7 Ah
Operating Temperature	0°C to +50°C
Weight	1.5 kg
Compatibility	Bosch accessories
