1. Symbols used
1.1 In the documentation
1.1.1 Warning notices - Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the con-
sequences of the hazard as well as preventive action.
Warning notices have the following structure:
Warning
symbol
KEY WORD – Nature and source of hazard!
Consequences of hazard in the event of
failure to observe action and information
given.
¶ Hazard prevention action and informati-
on.
The key word indicates the likelihood of occurrence and
the severity of the hazard in the event of non-observan-
ce:
Key word Probability of
occurrence
Severity of danger if inst-
ructions not observed
DANGER Immediate impen-
ding danger
Death or severe injury
WARNING Possible impending
danger
Death or severe injury
CAUTION Possible dangerous
situation
Minor injury
1.1.2 Symbols in this documentation
Symbol Designation Explanation
!
Attention Warns about possible property dama-
ge.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several
steps.
e
One-step
operation
Instruction consisting of one step.
Intermediate
result
An instruction produces a visible in-
termediate result.
"
Final result There is a visible final result on com-
pletion of the instruction.
1.2 On the product
! Observe all warning notices on products and ensu-
re they remain legible.
Disposal
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
1. Symbols used 11
1.1 In the documentation 11
1.1.1 Warning notices - Structure and
meaning 11
1.1.2 Symbols in this documentation 11
1.2 On the product 11
2. User instructions 12
2.1 Important information 12
2.1.1 Warranty 12
2.2 Safety instructions 12
2.2.1 Safety instructions for
handling AdBlue 12
2.2.2 Cleanliness rules for working on
theAdBlue system 12
3. Product description 13
3.1 Intended use 13
3.2 Extension set 0986610930 13
3.3 Overview of case contents 13
3.4 Scope of delivery 14
3.5 Special accessories 14
3.6 Functional description 14
3.6.1 Denoxtronic5.x systems 15
3.7 Test requirements 15
3.8 AdBlue system functional tests 16
4. Maintenance 16
4.1 Spare and wearing parts 16
4.2 Cleaning 17
4.3 Calibration 17
4.3.1 Calibrating the scale 0986610838 17
4.3.2 Inspecting weight 0986610839 17
5. Decommissioning 17
5.1 Change of location 17
5.2 Disposal and scrapping 17
6. Technical data 17
6.1 Dimensions and weights 17
6.2 Measurement functions 17
1 689 989 454 2019-08-01| Robert Bosch GmbH
Symbols used | 0 986 613 900 | 11 | en
