Item Description
4 Balanced audio line output socket: Connection to a public address system,
audio mixers or to a voice logging system for audio registration of all spoken
conference proceedings. Use standard line output cabling. 6.3mm (1/4") jacks
with the following pinning:
Tip: Live (+)
Ring: Return (-)
Sleeve: Shield
6 Balanced audio line input socket: Connection from audio source. Use standard
line output cabling. 6.3 mm (1/4") jacks with the following pinning:
Tip: Live (+)
Ring: Return (-)
Sleeve: Shield
5 Reset‑to‑default button: Sets the DCNM-WAP to factory default values. Press
and hold for at least 8 seconds to set all settings to factory default.
18 en | Installation Wireless Access Point DICENTIS
2015.03 | V1.01 | Installation Manual Bosch Security Systems B.V.
