14 | Hanging Bracket Kit
HANGING BRACKET KIT
Installation Instructions
All horizontal units come with hanging bracket
installation kit to facilitate suspended unit mounting
using threaded rod.Hanging brackets are to be installed
as shown in Figure #41.
Figure # 41
This kit includes the following:
(5) Brackets
(5) Rubber Vibration isolators
(8) Screws #10x1/2 (not used for these models)
(10) Bolts 1/4-28x12” Hex bolt
The following are needed and are to be field provided:
Threaded rod (3/8“ max dia)
Hex nuts
Washers (1-3/4“ min O.D.)
1. Remove and discard factory provided screws from
locations where hanging brackets will be installed
shown in Figure #42
Figure # 42
2. Mount 5 brackets to unit corner post using the Bolts
provided in the kit as shown on Figure # 43
Figure # 43
3. Install rubber grommet onto the brackets as shown in
Figure # 44
4. Hang the unit and assemble the field provided
threaded rod, nuts and washers on to the brackets as
shown in Figure # 44
Figure # 44
WARNING: Do not re-use screws removed
from the unit on step 1 to mount the
hanging brackets to the unit.
WARNING: Follow all applicable codes and
requirements when hanging this unit,
selecting threaded rod material, etc.
WARNING: Rods must be securely
anchored to the ceiling
