Bosch Greensource CDi Series - Blower Performance Data HZ Units Rev a

Troubleshooting | 51SM Series Heat Pump
8733942411 (2017/06)Revised 07-17
BLOWER PERFORMANCE DATA
(HZ) UNITS REV A
Models Fan
Speed
Rated
Airflow
Adjust Fan
Only
External Static Pressure (in of Water)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00
024- Part
Load
High 725 + 550 730 730 730 730 730 730 730 730 - -
Med 650 Normal A 480 650 650 650 650 650 650 650 650 - -
Low 500 - 375 500 500 500 500 500 500 500 500 - -
024- Full
Load
High 950 + 710 950 950 950 950 950 950 950 950 - -
Med 825 Normal A 615 825 825 825 825 825 825 825 825 - -
Low 725 - 550 730 730 730 730 730 730 730 730 - -
036- Part
Load
High 950 + 650 950 950 950 950 950 950 950 950 950 950
Med 800 Normal A 550 800 800 800 800 800 800 800 800 800 800
Low 750 - 515 750 750 750 750 750 750 750 750 750 750
036- Full
Load
High 1300 + 900 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300
Med 1100 Normal A 750 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100
Low 950 - 650 950 950 950 950 950 950 950 950 950 950
048- Part
Load
High 1400 + 970 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
Med 1300 Normal A 900 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300
Low 1100 - 760 1100 1100 1100 1100 1100 1100 1100 1100 1100 1100
048- Full
Load
High 1800 + 1240 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
Med 1600 Normal A 1100 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600
Low 1400 - 160 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
060- Part
Load
High 1800 + 1350 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
Med 1600 Normal A 1200 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600
Low 1400 - 1050 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
060- Full
Load
High 2200 + 1650 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200
Med 2000 Normal A 1500 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000
Low 1800 - 1350 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
070- Part
Load
High 2100 + 1575 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100
Med 1850 Normal A 1390 1850 1850 1850 1850 1850 1850 1850 1850 1850 1850
Low 1600 - 1200 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600
070- Full
Load
High 2500 + 1875 2500 2500 2500 2500 2500 2500 2500 2500 2500 2500
Med 2350 Normal A 1760 2350 2350 2350 2350 2350 2350 2350 2350 2350 2350
Low 2100 - 1575 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100
