SM 024 - 1 VT C - F L T A A B - C M G A N X X X D 7 X X X
X
5XXXXSBA
SM
PREMIUM SERIES
SIZE
024, 036,
048, 060, 070
VOLTAGE
1 208-230/60/1
CABINET CONFIGURATION
HZ- HORIZONTAL
VT- VERTICAL
CF- COUNTERFLOW
COAX OPTIONS
C- COPPER
N- CUPRO-NICKEL
WATER CONNECTIONS
F- FRONT
RETURN AIR CONFIGURATION
L- LEFT
R- RIGHT
DISCHARGE AIR CONFIGURATION
T- TOP (VT ONLY)
S- STRAIGHT (HZ ONLY)
E- END (HZ ONLY)
B- BOTTOM (CF ONLY)
FAN/MOTOR OPTIONS
A- CONSTANT AIRFLOW ECM
AIR COIL
D- DUOGUARD/SS DRAIN PAN (VT & CF ONLY)
T- TIN PLATED (HZ ONLY)
REVISION LEVEL
B- (VT & CF ONLY)
A- (HZ ONLY)
CODE STRING LEVEL
CHANNEL
B- BOSCH
STANDARD/SPECIAL
S- STANDARD
AGENCY OPTIONS
X- ETL (UL 1995)
OPEN
DRIVE SPEED (MC ONLY)
X- N/A
ELECTRIC HEAT
X- NONE
A- 5 kW
C- 10 kW
D- 15 kW
E- 20 kW
CABINET CONSTRUCTION
M- PAINTED STEEL/ ½” CLOSED CELL FOAM, EXTRA QUIET (TO INCLUDE
COMPRESSOR BLANKET AS STANDARD) (VT & CF ONLY)
H- PAINTED STEEL/ ½” CLOSED CELL FOAM (HZ ONLY)
APPLICATION
G- EXTENDED RANGE
GENERAL ELECTRICAL OPTIONS (UP TO 5 AVAILABLE PER UNIT)
X- AS DEFAULT FOR NON USED ELECTRICAL CODES
A- EMS RELAY
E- PUMP/VALVE RELAY
N- COMFORT ALERT MODULE
S- START ASSIST
REFRIGERATION CIRCUIT OPTIONS
X- NONE
D- HEAT RECOVERY PACKAGE
MOTOR HP/QTY (BELT DRIVE ONLY)
X- N/A
AIR FILTRATION
4- MERV8-2” W/ 4-SIDED FILTER RACK (VT & CF only)
5- MERV13- 2” W/4-SIDED FILTER RACK (HZ Only)
ECONOMIZER
X- NONE
WATER FLOW CONTROL OPTIONS
X- NONE
OPEN
CONTROLS
X- STANDARD
TRANSFORMER
7-75 VA
