Bosch Greensource CDi Series - Blower Performance Data VT;CF Rev B

SM Series Heat Pump
SM Series Heat Pump8733942411 (2017/07) Subject to change without prior notice
52 | Troubleshooting
Blower Performance Data
(VT/CF) units Rev B
Model
ECM
Board
setting
Rated
Airflow
DeHum
Airflow
External Static Pressure (in of Water)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
024- Fan
Only
+ 630 500 630 630 630 630 630 630 630 630 - -
Norm A 560 450 560 560 560 560 560 560 560 560 - -
- 490 390 490 490 490 490 490 490 490 - - -
024- Part
Load
+ 800 640 800 800 800 800 800 800 800 800 - -
Norm A 700 560 700 700 700 700 700 700 700 700 - -
- 600 480 600 600 600 600 600 600 600 - - -
024- Full
Load
+ 900 720 900 900 900 900 900 900 900 900 - -
Norm A 800 640 800 800 800 800 800 800 800 800 - -
- 700 560 700 700 700 700 700 700 700 - - -
036- Fan
Only
+ 945 760 945 945 945 945 945 945 945 945 945 945
Norm A 840 670 840 840 840 840 840 840 840 840 840 840
- 735 590 735 735 735 735 735 735 735 735 735 735
036- Part
Load
+ 1200 960 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
Norm A 1050 840 1050 1050 1050 1050 1050 1050 1050 1050 1050 1050
- 900 720 900 900 900 900 900 900 900 900 900 900
036- Full
Load
+ 1350 1080 1350 1350 1350 1350 1350 1350 1350 1350 1350 1350
Norm A 1200 960 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200
- 1050 840 1050 1050 1050 1050 1050 1050 1050 1050 1050 1050
048- Fan
Only
+ 1260 1010 1260 1260 1260 1260 1260 1260 1260 1260 1260 1260
Norm A 1120 900 1120 1120 1120 1120 1120 1120 1120 1120 1120 1120
- 1015 810 1015 1015 1015 1015 1015 1015 1015 1015 1015 1015
048- Part
Load
+ 1450 1160 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
Norm A 1300 1040 1300 1300 1300 1300 1300 1300 1300 1300 1300 1300
- 1150 920 1150 1150 1150 1150 1150 1150 1150 1150 1150 1150
048- Full
Load
+ 1800 1440 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
Norm A 1600 1280 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600
- 1450 1160 1450 1450 1450 1450 1450 1450 1450 1450 1450 1450
060- Fan
Only
+ 1540 1230 1540 1540 1540 1540 1540 1540 1540 1540 1540 1540
Norm A 1365 1090 1365 1365 1365 1365 1365 1365 1365 1365 1365 1365
- 1225 980 1225 1225 1225 1225 1225 1225 1225 1225 1225 1225
060- Part
Load
+ 1800 1440 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
Norm A 1550 1240 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600
- 1400 1120 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
060- Full
Load
+ 2200 1760 2200 2200 2200 2200 2200 2200 2200 2200 2200 2200
Norm A 1950 1560 1950 1950 1950 1950 1950 1950 1950 1950 1950 1950
- 1750 1400 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
070- Fan
Only
+ 1680 1340 1680 1680 1680 1680 1680 1680 1680 1680 1680 1680
Norm A 1575 1260 1575 1575 1575 1575 1575 1575 1575 1575 1575 1575
- 1330 1060 1330 1330 1330 1330 1330 1330 1330 1330 1330 1330
070- Part
Load
+ 2000 1600 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000
Norm A 1800 1440 1800 1800 1800 1800 1800 1800 1800 1800 1800 1800
- 1550 1240 1550 1550 1550 1550 1550 1550 1550 1550 1550 1550
070- Full
Load
+ 2400 1920 2400 2400 2400 2400 2400 2400 2400 2400 2250 2250
Norm A 2250 1800 2250 2250 2250 2250 2250 2250 2250 2250 2250 2250
- 1900 1520 1900 1900 1900 1900 1900 1900 1900 1900 1900 1900
