Bosch Greensource CDi Series - Page 47

Troubleshooting | 47SM Series Heat Pump
8733942411 (2017/06)Revised 07-17
SM060 Full Load
COOLING HEATING
Entering
Water
°F
Water
flow
GPM
Discharge
Pressure
(PSIG)
Suction
Pressure
(PSIG)
Subcooling
°F
Superheat
°F
Water
Temp Rise
°F
Air Temp
Drop °F
Entering
Water
°F
Water
flow
GPM
Discharge
Pressure
(PSIG)
Suction
Pressure
(PSIG)
Subcooling
°F
Superheat
°F
Water
Temp
Drop °F
Air
Temp
Rise °F
30
7 198 - 202 128 - 134 33 - 36 10 - 12 23 - 28 23 - 28
20
7 262 - 321 56 - 69 12 - 20 9 - 24 7 - 11 17 - 26
12 168 - 172 126 - 132 24 - 26 10 - 12 14 - 17 24 - 29 12 269 - 329 62 - 76 9 - 17 9 - 23 5 - 7 18 - 27
15 161 - 164 126 - 131 21 - 23 9 - 11 11 - 13 24 - 29 15 271 - 332 64 - 78 9 - 16 9 - 23 4 - 6 19 - 28
40
7 206 - 251 119 - 146 20 - 53 7 - 18 15 - 40 20 - 30
30
7 276 - 337 68 - 83 13 - 21 8 - 23 9 - 13 19 - 29
12 177 - 216 118 - 144 14 - 38 6 - 17 9 - 24 21 - 31 12 284 - 347 75 - 91 10 - 18 8 - 22 5 - 8 21 - 31
15 169 - 206 117 - 143 12 - 33 6 - 17 7 - 19 21 - 31 15 286 - 350 77 - 94 9 - 17 8 - 22 4 - 7 21 - 32
50
7 234 - 286 121 - 148 25 - 36 7 - 18 20 - 30 20 - 30
40
7 290 - 354 80 - 98 14 - 22 8 - 21 10 - 15 22 - 33
12 203 - 248 119 - 146 18 - 27 6 - 15 12 - 17 20 - 30 12 299 - 366 89 - 109 11 - 19 8 - 21 6 - 9 24 - 35
15 195 - 238 119 - 145 16 - 25 7 - 17 9 - 14 20 - 30 15 302 - 369 92 - 112 10 - 17 8 - 20 5 - 8 24 - 36
60
7 265 - 324 123 - 150 24 - 35 7 - 18 19 - 29 19 - 29
50
7 304 - 372 94 - 115 15 - 24 8 - 20 11 - 17 24 - 37
12 233 - 284 121 - 148 17 - 26 7 - 18 11 - 17 20 - 30 12 315 - 386 104 - 128 12 - 20 8 - 20 7 - 11 26 - 39
15 224 - 274 120 - 147 15 - 24 7 - 18 9 - 13 20 - 30 15 319 - 390 108 - 132 11 - 18 7 - 20 6 - 9 27 - 40
70
7 300 - 366 125 - 152 23 - 33 7 - 18 19 - 28 19 - 28
60
7 320 - 391 109 - 133 17 - 26 7 - 20 13 - 19 27 - 41
12 266 - 325 123 - 150 16 - 25 7 - 18 11 - 16 19 - 29 12 334 - 408 123 - 150 13 - 21 7 - 19 8 - 12 29 - 44
15 257 - 314 122 - 149 14 - 23 7 - 18 9 - 13 19 - 29 15 338 - 414 127 - 155 11 - 19 7 - 19 7 - 10 30 - 45
80
7 337 - 411 126 - 154 21 - 32 7 - 19 18 - 27 18 - 27
70
7 337 - 412 126 - 154 18 - 28 7 - 19 14 - 21 30 - 45
12 302 - 369 125 - 152 15 - 24 7 - 18 11 - 16 19 - 28 12 353 - 432 142 - 174 14 - 22 7 - 19 9 - 14 33 - 49
15 293 - 358 124 - 152 13 - 22 7 - 18 8 - 13 19 - 28 15 359 - 438 148 - 181 12 - 20 7 - 18 8 - 11 33 - 50
90
7 377 - 461 128 - 156 20 - 30 7 - 19 18 - 27 18 - 27
80
7 355 - 434 144 - 176 20 - 30 7 - 18 16 - 24 33 - 49
12 342 - 418 126 - 154 14 - 23 7 - 18 10 - 15 18 - 27 12 374 - 457 164 - 201 15 - 23 7 - 18 10 - 15 36 - 54
15 333 - 407 126 - 154 13 - 21 7 - 18 8 - 12 18 - 27 15 380 - 465 171 - 209 13 - 21 7 - 18 8 - 13 37 - 55
100
7 421 - 515 129 - 158 19 - 29 7 - 19 18 - 26 17 - 26
90
7 373 - 456 164 - 200 21 - 32 7 - 18 18 - 26 36 - 54
12 386 - 472 128 - 156 14 - 22 7 - 19 10 - 15 18 - 27
12 396 - 484 189 - 231 16 - 25 7 - 18 11 - 17 39 - 59
15 377 - 461 128 - 156 12 - 20 7 - 19 8 - 12 18 - 27
15 403 - 493 197 - 241 14 - 22 7 - 18 9 - 14 40 - 60
110
7 469 - 573 131 - 160 18 - 27 7 - 20 17 - 26 17 - 25
100
7 393 - 481 186 - 227 23 - 34 7 - 18 19 - 29 39 - 58
12 435 - 531 130 - 158 13 - 21 7 - 20 10 - 15 17 - 26
12 418 - 511 216 - 264 17 - 26 7 - 17 12 - 18 42 - 63
15 426 - 520 129 - 158 12 - 19 7 - 19 8 - 12 17 - 26
15 426 - 521 226 - 277 15 - 23 6 - 17 10 - 15 44 - 65
This chart shows approximate temperatures and pressures for a unit in good normal operation. The values shown are meant as
a guide only and should not be used to estimate system charge. This chart assumes rated air flow and 80º D.B/67º W.B. Entering
air temperature in cooling, 70º D.B entering air temperature in heating. Heating data at entering fluid temperatures below 50º
assumes the use of antifreeze. As a result of continuing research and development, specifications are subject to change without
notice.
