Overview
3Overview
Figure 2: Pedelec viewed from right: BULLS Copperhead Evo AM3 used as example
1 Front wheel
2Fork
3 Front wheel guard
4 Headlight
5 Handlebars
6Stem
7Frame
8 Seat post
9 Saddle
10 Pannier rack
11 Reflector and rear light
12 Rear wheel guard
13 Kickstand
14 Rear wheel
15 Chain
16 Chain guard
17 Motor
18 Pedal
19 Battery and nameplate
1
2
4
8910
15 16 19
5
67
17
3
1112
13
14
18
