Bosch PCM 10 - Product Elements; Intended Use; Noise;Vibration Information; Technical Data

English–61 609 929 J60 • (05.12) PS
3 FUNCTION
While reading the operating instructions,
refer to the corresponding illustrations of
the power tool on the front pages.
Intended Use
The power tool is intended as a stationary machine for
making straight lengthways and crossways cuts in
wood. Horizontal mitre angles of 45° to +45° as well
as vertical bevel angles of 0° to 45° are possible.
The performance of the power tool was designed for
sawing hard and soft wood as well as chip and fibre
boards.
Noise/Vibration Information
Measured values are determined according to stand
ard EN 61 029 procedures.
The Aweighted noise levels of the tool are typically:
Sound pressure level: 91 dB(A)
Sound power level: 104 dB(A)
Measurement uncertainty K = 3 dB
Wear ear protection!
The handarm vibration is typically below 2.5 m/s
2
.
Technical Data
Switchon actions cause brief drops in the mains volt
age. For unfavourable mains conditions, interference
with other equipment can occur.
For mains impedance of less than 0,363 Ω, no interfer
ence can be expected.
Product Elements
The numbering of the machine elements refers to the
illustrations of the power tool on the front pages of the
operating instructions.
1 Release button for the tool arm
2 Handle
3 Protective hood
4 Swinging guard
5 Sliding saw table extension
6 Extension hoop
7 Fence
8 Holes for quick action clamp
9 Table insert
10 Scale for mitre angle (horizontal)
11 Lever for mitre angle adjustment (horizontal)
12 Locking knob for variable mitre angles (horizontal)
13 Detents for standard mitre angles
14 Saw table
15 Mounting holes
16 Holes for extension hoop
17 Stop bolt for 0° bevel angle (vertical)
18 Stop bolt for 45° bevel angle (vertical)
19 Roller
20 Dust bag
21 Saw blade
22 Transport handle
23 Cable holder
24 Cover
25 Sawdust ejector
26 Locking knob for variable bevel angle (vertical)
27 Transport locking pin
28 Sockethead screws (6 mm) of the fence
29 Allen key (6 mm) / Phillips screwdriver
30 Battery compartment
31 On/Off switch
32 Switch for the Power Light
33 Switch for laser
34 Allen key (2 mm)
35 Adjustment screw for vertical laser positioning
36 Knurled screw
37 Adjustment screw for horizontal laser positioning
38 Length stop
39 "Extension hoop" attachment set
40 Attachment piece on the housing
Compound Mitre Saw PCM 10
Order number 3 603 L01 0..
Rated input power [W] 1 500
Voltage [V] 230
Frequency [Hz] 50
No load speed [min
1
] 4 700
Laser type 650 nm, <1 mW
Laser class 2
Weight
(according to EPTA Proce
dure 01/2003)
[kg] 13.8
Protection class / II
For maximum work piece dimensions,
see the "Working Instructions" Section
Dimensions of Suitable Saw Blades
Saw blade diameter [mm] 254
Disk thickness of the saw blade [mm] 1.4  2.0
Mounting hole diameter [mm] 30
