Title
Rexroth IndraDyn …
Kind of documentation
Document typecode
1)
DOK-MOTOR*-…
Material number
R911…
L Ironless Linear Motors MCL Project Planning Manual MCL********-PRxx-EN-P 330592
S Synchronous Motors MKE Project Planning Manual MKE*GEN2***-PRxx-EN-P 297663
S Synchronous Motors MSK Project Planning Manual MSK********-PRxx-EN-P 296289
S Synchronous Motors MSM Data Sheet MSM********-DAxx-EN-P 329338
S Synchronous Motors QSK Project Planning Manual QSK********-PRxx-EN-P 330321
T Synchronous Torque Motors Project Planning Manual MBT********-PRxx-EN-P 298798
1) In the document typecodes, "xx" is a wild card for the current
edition of the documentation (example: PR01 is the first edition
of a Project Planning Manual)
Tab. 1-4: Documentations – Motors
1.2.3 Gearboxes
Title Kind of documentation
Document typecode
1)
Material number
Rexroth GTP
Planetary Gearboxes
Project Planning Manual DOK-GEAR**-GTP********-PRxx-EN-P R911267495
Rexroth GTM
Planetary Gearboxes
Project Planning Manual DOK-GEAR**-GTM********-PRxx-EN-P R911297321
Rexroth GTE
Planetary Gearboxes
Project Planning Manual DOK-GEAR**-GTE********-PRxx-EN-P R911308842
1) In the document typecodes, "xx" is a wild card for the current
edition of the documentation (example: RE02 is the second ed‐
ition of a Reference Book)
Tab. 1-5: Documentations – Gearboxes
1.2.4 Cables
Title Kind of documentation
Document typecode
1)
DOK-CONNEC-…
Material number
R911…
Rexroth Connection Cables
IndraDrive and IndraDyn
Selection Data CABLE*INDRV-CAxx-EN-P 322949
1) In the document typecodes, "xx" is a wild card for the current
edition of the documentation (example: CA02 is the second ed‐
ition of the documentation "Selection Data")
Tab. 1-6: Documentations – Cables
1.2.5 Firmware
Title
Rexroth IndraDrive ...
Kind of documentation
Document typecode
1)
DOK-INDRV*-…
Material number
R911…
Power Supply Basic PSB-19
Functions
Application Manual PSB-19VRS**-APxx-EN-P 345602
MPx-19
Version Notes
Release Notes MP*-19VRS**-RNxx-EN-P 345604
Bosch Rexroth AG DOK-INDRV*-SI3-**VRS**-AP06-EN-P
Rexroth IndraDrive Integrated Safety Technology "Safe Torque Off" (as of MPx-16)
8/149
