Bosch Rexroth IndraDrive CS - Page 88

HCS03.1E-W0xxx-A-05-xxxN) with CSB02 or CSH02 control section
● IndraDrive M (HMS01, HMS02) with CSB02 or CSH02 control section
● IndraDrive M (HMD01) with CDB02
control section
All IndraDrive C and IndraDrive M power sections produced since
2007 can use the Cxx02
control sections. See power section type
plate: "FD" must say at least "07W01".
● IndraDrive ML (HMU05.1) with CSB02.5 or CSH02.5 control section
For pin assignments and technical data of the optional safety
technology module "L3", please refer
to the Appendix: "X49,
optional safety technology L3 or L4".
Optional safety technology module "L4"
Using the "Safe Torque Off
" and "Safe Brake Control" function requires the
optional safety technology module "L4". The optional module can be ordered
for the following controllers:
● IndraDrive Cs Basic (HCS01.1E-W00**-A0*-B)
● IndraDrive Cs Economy (HCS01.1E-W00**-A0*-E)
● IndraDrive Cs Advanced (HCS01.1E-W00**-A0*-A)
For pin assignments and technical data of the optional safety
technology module "L4", please refer
to the Appendix: "X49,
optional safety technology L3 or L4".
DOK-INDRV*-SI3-**VRS**-AP06-EN-P
Rexroth IndraDrive Integrated Safety Technology "Safe Torque Off" (as of MPx-16)
Bosch Rexroth AG 85/149
Commissioning the safety technology
