Commissioning steps
Step 0: Condition as supplied and
initialization
The "Safe Torque Off" function is always active and cannot be deactivated.
During the booting process, the drive system is
in the "STO" operating status;
i.e., the output stage has been switched off via two channels.
After the booting process, the safety function "Safe Torque Off" is active.
When the drive is switched from operating mode to parameter mode, the
functionality of the "Safe Torque Off" function is maintained, i.e. according to
the selection, the "Safe Torque Off" function becomes active or not.
Step 1: Connecting and wiring the
"Safe Torque Off" function
The connection and wiring of the "Safe Torque Off" function depends on the
option used to make the selection at the drive or the drive connection box
KCU02.
The "Examples of application for IndraDrive Mi" chapter shows the different
options of selection and wiring.
The table below shows the dependances of the wiring of the optional safety
technology module:
KCU02
KSM02 / KMS02
as zone beginner
KSM02 / KMS02
as zone node
Selection via a passive
safety unit
Dynamization outputs
Dyn_Ch1 and Dyn_Ch2
X49/6 and X49/5 X141/8 and X141/12
Connector RBS0023 at
X141
Hybrid cable at
X103.1 / X103.2
Selection inputs SI_Ch1
and SI_Ch2
X49/3 and X49/1 X141/1 and X141/2
24V supply X49/4 X141/4
0V supply X49/2 X141/10
Selection via an active
safety unit
Dynamization outputs
Dyn_Ch1 and
Dyn_Ch2
- -
Selection inputs SI_Ch1
and SI_Ch2
X49/3 and X49/1 X141/1 and X141/2
24V supply - -
0V supply X49/2 X141/10
Step 3: Configuring the safety
function
The diagnostic message output and
the error reaction of the L options can be
configured. The configuration can be made in IndraWorks. (Call the
configuration dialog in IndraWorks: Drive-Integrated Safety
Technology ▶ Configuration.)
Bosch Rexroth AG DOK-INDRV*-SI3-**VRS**-AP06-EN-P
Rexroth IndraDrive Integrated Safety Technology "Safe Torque Off" (as of MPx-16)
92/149
Commissioning the safety technology
